【Characteristic】
High Stability and High Repeatability
Big cooling capacity over than 250Watts
Simple for operation, as long as the use of temperature controller △ and ▽ keys,to modify the control temperature
Small size,Low vibration.
【Use】
●Precision optics
●Precision laser
●Medium temperature control
●Microbiological cultivate
【Specifications】
| TYPE |
TC-200 |
Control range |
+5℃ ～ +35℃ |
Ambient |
0℃～+50℃（None Dewfall），humidity less than 85% |
Temperature accuracy |
±0.01℃ |
Temperature display |
Actual temperature of water tank, Setting temperature, digital display |
Heating capacity |
250W |
| Cooling capacity |
>250 watts @ 20°C (20°C ambient) |
Pump |
Centrifugal pump ≥2L/min @ 1bar or gear pump ≥3L/min @ 1.5bar selectable
|
Size |
245（W）×350（D）×300mm（H） |
Weight |
Approx 22kg
|
Power |
220VAC Max 5A；110VAC Max.10A |
* Note: Cooling capacity will vary with configuration |
